Additional data |
|---|
| Rated input power | 701 W |
| No-load speed, 1st gear | 0 – 3,000 rpm |
| Power output | 351 W |
| Impact rate at no-load speed | 0 – 48,000 bpm |
| Drill spindle connecting thread | 1/2″-20 UNF |
| Chuck capacity, min./max. | 1.5 – 13 mm |
Drilling range |
|---|
| Drilling diameter in wood | 30 mm |
| Drilling diameter in concrete | 16 mm |
| Drilling diameter in steel | 12 mm |
| Drilling diameter in masonry | 18 mm |
Total vibration values (Drilling in metal) |
|---|
| Vibration emission value ah | 1.5 m/s² |
| Uncertainty K | 2.7 m/s² |
Total vibration values (Impact drilling in concrete) |
|---|
| Vibration emission value ah | 3.5 m/s² |
| Uncertainty K | 23 m/s² |
Total vibration values (Screwdriving) |
|---|
| Vibration emission value ah | 1.5 m/s² |
| Uncertainty K | 2.5 m/s² |
Noise/vibration information |
|---|
| Sound pressure level | 98 dB(A) |
| Sound power level | 109 dB(A) |
| Uncertainty K | 3 dB |
Drilling in metal |
|---|
| Vibration emission value ah | 1.5 m/s² |
| Uncertainty K | 2.7 m/s² |
Impact drilling in concrete |
|---|
| Vibration emission value ah | 3.5 m/s² |
| Uncertainty K | 23 m/s² |
Screwdriving |
|---|
| Vibration emission value ah | 1.5 m/s² |
| Uncertainty K | 2.5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 98 dB(A); Sound power level 109 dB(A). Uncertainty K= 3 dB.
