TECHNICAL DATA
Performance data |
|
|---|---|
| Impact rate at rated speed | 1,380 – 2,720 bpm |
| Rated speed | 150 – 305 rpm |
Additional data |
|
|---|---|
| Rated input power | 1,500 W |
| Impact energy (according to EPTA 05/2016) | 12.5 J |
| Tool holder | SDS max |
Drilling range |
|
|---|---|
| Drilling dia. concrete, hammer drill bits | 12 – 45 mm |
| Opt. appl. range concrete, hammer drill bits | 20 – 40 mm |
| Drilling dia. concrete, breakthrough drill bits | 80 – 80 mm |
| Drilling diameter in concrete with core cutters | 125 mm |
| Max. drilling diameter masonry, core cutters | 45 mm |
| Max. drilling diameter in metal | 125 mm |
| Max. drilling diameter in wood | 80 mm |
Total vibration values (Hammer drilling in concrete) |
|
|---|---|
| Vibration emission value ah | 18.5 m/s² |
| Uncertainty K | 1.5 m/s² |
Total vibration values (Chiselling) |
|
|---|---|
| Vibration emission value ah | 14 m/s² |
| Uncertainty K | 1.5 m/s² |
Hammer drilling in concrete |
|
|---|---|
| Vibration emission value ah | 18.5 m/s² |
| Uncertainty K | 1.5 m/s² |
Chiselling |
|
|---|---|
| Vibration emission value ah | 14 m/s² |
| Uncertainty K | 1.5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 96 dB(A); Sound power level 107 dB(A). Uncertainty K= 3 dB.
