Additional data |
|---|
| Battery voltage | 18.0 V |
| Impact energy (according to EPTA 05/2016) | 7 J |
| Weight excl. battery | 5.1 kg |
| Impact rate at rated speed | 0 – 2,900 bpm |
| Rated speed | 0 – 500 rpm |
| Tool holder | SDS max |
Drilling range |
|---|
| Opt. app. range in concrete with hammer drill bits | 14 – 35 mm |
| Drilling dia. in concrete with hammer drill bits | 14 – 35 mm |
Total vibration values (Hammer drilling in concrete) |
|---|
| Vibration emission value ah | 11.4 m/s² |
| Uncertainty K | 1.5 m/s² |
Total vibration values (Chiselling) |
|---|
| Vibration emission value ah | 10.8 m/s² |
| Uncertainty K | 1.5 m/s² |
Noise/vibration information |
|---|
| Sound pressure level | 95 dB(A) |
| Sound power level | 106 dB(A) |
| Uncertainty K | 3 dB |
Hammer drilling in concrete |
|---|
| Vibration emission value ah | 11.4 m/s² |
| Uncertainty K | 1.5 m/s² |
Chiselling |
|---|
| Vibration emission value ah | 10.8 m/s² |
| Uncertainty K | 1.5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 95 dB(A); Sound power level 106 dB(A). Uncertainty K= 3 dB.
