Additional data |
|---|
| Battery voltage | 18.0 V |
| Weight excl. battery | 1.8 kg |
| Stroke rate at no load | 0 – 2,700 spm |
| Stroke height | 23 mm |
| Bevel angle, to | 45 ° |
| Bevel angle, from | 0 ° |
| Bevel angle | 0 – 45 ° |
Cutting depth |
|---|
| Cutting depth in wood | 120 mm |
| Cutting depth in aluminium | 20 mm |
| Cutting depth in unalloyed steel | 8 mm |
Total vibration values (Sawing wood) |
|---|
| Vibration emission value ah | 6 m/s² |
| Uncertainty K | 1.5 m/s² |
Total vibration values (Sawing sheet metal) |
|---|
| Vibration emission value ah | 8.5 m/s² |
| Uncertainty K | 1.5 m/s² |
Noise/vibration information |
|---|
| Sound pressure level | 83 dB(A) |
| Sound power level | 94 dB(A) |
| Uncertainty K | 5 dB |
Sawing wood |
|---|
| Vibration emission value ah | 6 m/s² |
| Uncertainty K | 1.5 m/s² |
Sawing sheet metal |
|---|
| Vibration emission value ah | 8.5 m/s² |
| Uncertainty K | 1.5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 83 dB(A); Sound power level 94 dB(A). Uncertainty K= 5 dB.
