Basic specifications
Accuracy guaranteed: 1 year
| Rated output voltage | 500 V DC | |||||
|---|---|---|---|---|---|---|
| Effective maximum indicated value | 1000 MΩ | |||||
| Accuracy 1st effective measuring range | ±2 % of scale length, 1 M to 500 MΩ | |||||
| Lower limit resistance | 0.5 MΩ (measurement resistance value to maintain testing voltage) | |||||
| Overload protection | 600 V AC (10 sec.) | |||||
| AC voltage range | 0 to 600 V (50/60 Hz), ±5 % of maximum scale value accuracy, 500 kΩ or more input resistance |
|||||
| Other functions | Bright LED luminous scale, Drop proof (on concrete, 1 m/1 time), Battery check, Live circuit check, Auto discharge | |||||
| Power supply | LR6 (AA) alkaline batteries ×4, Continuous use: 20 hours (no load) | |||||
| Dimensions and mass | 159 mm (6.26 in) W × 177 mm (6.97 in) H × 53 mm (2.09 in) D, 610 g (21.5 oz), (including battery, excluding test lead) | |||||
| Accessories | Test Lead L9787 ×1, LR6 (AA) alkaline batteries ×4, Instruction manual ×1, Shoulder strap ×1 | |||||
