Additional data
|
Rated input power |
850 W |
No-load speed, 1st gear |
0 – 1,000 rpm |
No-load speed, 2nd gear |
3,000 rpm |
Power output |
430 W |
Impact rate at no-load speed |
0 – 17,000 / 51,000 bpm |
Rated speed |
800 / 2,060 rpm |
Rated torque |
5.2 / 2.0 Nm |
Drill spindle connecting thread |
1/2″-20 UNF |
Chuck capacity, min./max. |
1.5 – 13 mm |
Max. torque |
36.0 Nm |
Drilling range
|
Drilling diameter in wood |
40 / 25 mm |
Drilling diameter in steel |
13 / 8 mm |
Drilling dia. in stone |
20 / 15 mm |
Drilling diameter in masonry |
20 / 15 mm |
Total vibration values (Drilling in metal)
|
Vibration emission value ah |
3 m/s² |
Uncertainty K |
1.5 m/s² |
Total vibration values (Impact drilling in concrete)
|
Vibration emission value ah |
15 m/s² |
Uncertainty K |
2 m/s² |
Total vibration values (Screwdriving)
|
Vibration emission value ah |
2.5 m/s² |
Uncertainty K |
1.5 m/s² |
Total vibration values (Thread-cutting)
|
Vibration emission value ah |
2.5 m/s² |
Uncertainty K |
1.5 m/s² |
Noise/vibration information
|
Sound pressure level |
99 dB(A) |
Sound power level |
110 dB(A) |
Uncertainty K |
5 dB |
Drilling in metal
|
Vibration emission value ah |
3 m/s² |
Uncertainty K |
1.5 m/s² |
Impact drilling in concrete
|
Vibration emission value ah |
15 m/s² |
Uncertainty K |
2 m/s² |
Screwdriving
|
Vibration emission value ah |
2.5 m/s² |
Uncertainty K |
1.5 m/s² |
Thread-cutting
|
Vibration emission value ah |
2.5 m/s² |
Uncertainty K |
1.5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 99 dB(A); Sound power level 110 dB(A). Uncertainty K= 5 dB.
